Gigabyte B840M DS3H WIFI6 je matična ploča namenjena AMD AM5 procesorima sa B840 čipsetom. Podržava DDR5 memoriju do 8200MHz (O.C) sa kapacitetom do 256GB, poseduje 4x SATA portove i M.2 slot za SSD. Ploča je opremljena integrisanim WIFI6 modulom za brzu bežičnu konektivnost.

Procesorsko ležište (socket): AMD® AM5 Čipset: AMD® B840 Tip memorije: DDR5 Memorijski slotovi: 4x DDR5 Podržane memorije: do 8200(O.C) Maksimalna ukupna memorija: 256GB 4x SATA 6Gb/s RAID 0 1 10 1 x M.2 connector (M2A_CPU), integrated in the CPU, supporting Socket 3, M key, type 2580/2280 SSDs: AMD Ryzen™ 9000/7000 Series Processors support PCIe 4.0 x4/x2 SSDs AMD Ryzen™ 8000 Series-Phoenix 1 Processors support PCIe 4.0 x4/x2 SSDs AMD Ryzen™ 8000 Series-Phoenix 2 Processors support PCIe 4.0 x4/x2 SSDs 1 x M.2 connector (M2B_CPU), integrated in the CPU, supporting Socket 3, M key, type, type 25110/22110/2580/2280 SSDs: AMD Ryzen™ 9000/7000 Series Processors support PCIe 4.0 x4/x2 SSDs AMD Ryzen™ 8000 Series-Phoenix 1 Processors support PCIe 4.0 x4/x2 SSDs AMD Ryzen™ 8000 Series-Phoenix 2 Processors support PCIe 4.0 x2 SSDs LAN: Realtek® 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps) Realtek® Wi-Fi 6 RTL8851BE, WIFI a, b, g, n, ac, ax, supporting 2.4/5 GHz carrier frequency bands BLUETOOTH 5.3 Realtek 7.1 Surround Sound High Definition Audio CODEC 1 x USB Type-C® port, with USB 3.2 Gen 1 support 2 x USB 3.2 Gen 1 ports 4 x USB 2.0/1.1 ports Format: Micro ATX Form Factor
